Wheel Spacer 30mm 5×120 M14x1.5 CB70.1 with Centring Ring – Land Rover, Disco 2, Range Rover
21,00 €
30mm duralumin wheel spacer, 5×120 bolt pattern, M14x1.5 thread and 70.1 mm centre bore, with centring ring. Widens the track and clears oversized off-road tyres.
- Thickness: 30mm
- PCD / CB: 5×120 / 70.1 mm
- Thread: M14x1.5
- Fits: Land Rover, Disco 2, Range Rover
Price is per single piece.
In stock
Size and packaging guidelines
| Specification | Chair | Armchair | Sofas |
| Height | 37" | 42" | 42" |
| Width | 26.5" | 32.5" | 142" |
| Depth | 19.5" | 22.5" | 24.5" |
| Assembly Required | No | No | Yes |
| Packaging Type | Box | Box | Box |
| Package Weight | 55 lbs. | 64 lbs. | 180 lbs. |
| Packaging Dimensions | 27" x 26" x 39" | 45" x 35" x 24" | 46" x 142" x 25" |
Wheel spacer 30mm 5×120 M14x1.5
This 30mm wheel spacer adapts a 5×120 hub while adding track width. Duralumin construction keeps the added unsprung mass minimal, and the 70.1 mm bore locates the spacer squarely on the hub.
Technical specification
- Thickness: 30mm
- Bolt pattern (PCD): 5×120 mm
- Thread: M14x1.5
- Centre bore (CB): 70.1 mm
- Centring ring: Yes – included
- Material: Duralumin (aluminium alloy)
- Model: OFM096
- Weight: 1.5 kg
- Supplied: Price is per single piece
Vehicle compatibility
Suits Land Rover, Disco 2, Range Rover. Check your hub bolt pattern, thread and centre bore before ordering.
What a wheel spacer does
Fitting a spacer moves the wheel outboard by its thickness. That widens the track, which improves lateral stability, and it creates clearance between the tyre sidewall and the suspension, steering arms and chassis – the usual limit when moving to oversized off-road tyres after a lift.
Fitting and safety
Spacers must be fitted to clean, flat hub faces and the nuts torqued to the vehicle manufacturer’s specification, then re-checked after the first 50-100 km. The centring ring locates the wheel on the hub so the load is carried by the hub face rather than the studs. Fitting by a specialist 4×4 workshop is strongly recommended.
The price shown is for one piece. Order the quantity you need – most builds take four.
| Weight | 1,5 kg |
|---|---|
| Dimensions | 12 × 12 × 3 cm |
| Brand | OFM4X4 |
| Vehicle Compatibility | Discovery II, Land Rover |
| Material | Aluminium |
| Spacer Model | OFM096 |
| Centring Ring | Yes |
| Spacer Thickness | 30 mm |
| Thread Size | M14 x 1.5 |
| Centre Bore (CB) | 70.1 mm |
| Bolt Pattern (PCD) | 5 x 120 |
